Panasonic SA-MAX8000 - Voltage and Waveform Measurement; Voltage Measurement

77
14 Voltage and Waveform Measurement
14.1. Voltage Measurement
Note:
• Indication Voltage Values are in standard values for the unit measured by the DC electronic circuit tester (high-impedance) with
the chassis taken as standard.
Therefore, there may exist some errors in voltage values, depending on the internal impedance of the DC circuit tester.
• Circuit voltage and waveform described herein shall be regarded as reference information when probing defect point because it
may differ from actual measuring value due to difference of Measuring instrument and its measuring condition and product itself.
14.1.1. Main P.C.B. (1/5)
REF NO.
MODE 1234567891011121314151617181920
PLAY 3.3 3 3.3 3.3 3.3 3.3 1.6 3.3 3.3 3.3 3.3 0 0 3.3 3.3 0 3.3 1.6 0 0
STANDBY 3.3 3 3.3 3.3 3.3 3.3 1.6 3.3 3.3 3.3 3.3 0 0 3.3 3.3 0 3.3 1.6 0 0
REF NO.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
PLAY 3 3.3 0.2 2.9 3.3 3.3 0 0 3.3 0 3.3 0 1.6 1.1 1 0.8 0.8 0.8 1.6 0.8
STANDBY 3 3.3 0.2 2.9 3.3 3.3 0 0 3.3 0 3.3 0 1.6 1.1 1 0.8 0.8 0.8 1.6 0.8
REF NO.
MODE 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
PLAY 0.8 0 0 0 1.6 0.7 3.2 1.7 3.2 1.6 1.6 1.6 0 1.6 1.6 0 3.3 0 1.6 1.6
STANDBY 0.8 0 0 0 1.6 0.7 3.2 1.7 3.2 1.6 1.6 1.6 0 1.6 1.6 0 3.3 0 1.6 1.6
REF NO.
MODE 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
PLAY 1.6 1.6 1.6 1.6 1.6 0 1.7 1.8 1.8 1.8 0 0 3.3 3.3 3.3 3.3 1.6 3.3 3.3 0
STANDBY 1.6 1.6 1.6 1.6 1.6 0 1.7 1.8 1.8 1.8 0 0 3.3 3.3 3.3 3.3 1.6 3.3 3.3 0
REF NO.
MODE 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100
PLAY 0.8 1.6 1.6 0.4 0 3.3 1.5 3.3 3.3 0 0 1.6 0 3.3 3.2 3.3 0.2 0.2 0 0.2
STANDBY 0.8 1.6 1.6 0.4 0 3.3 1.5 3.3 3.3 0 0 1.6 0 3.3 3.2 3.3 0.2 0.2 0 0.2
REF NO.
MODE 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120
PLAY 3.1 3.2 0 0.2 3.1 3.1 3.1 0 1.8 1.6 1.6 1.6 3.2 3.1 0 1.5 3.2 3.3 3.3 3.3
STANDBY 3.1 3.2 0 0.2 3.1 3.1 3.1 0 1.8 1.6 1.6 1.6 3.2 3.1 0 1.5 3.2 3.3 3.3 3.3
REF NO.
MODE 121 122 123 124 125 126 127 128
PLAY 1.6 3.2 0 1.1 1.5 1.5 1.4 1.5
STANDBY 1.6 3.2 0 1.1 1.5 1.5 1.4 1.5
REF NO.
MODE 1234
PLAY 0 3.3 1.7 3.3
STANDBY 0 3.3 1.7 3.3
REF NO.
MODE 1234567891011121314151617181920
PLAY 00003.303.303.33.203.203.303.303.33.30
STANDBY 00003.303.303.33.203.203.303.303.33.30
REF NO.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
PLAY 0 0 0 3.3 3.2 3.2 3.3 3.3 0 0 3.2 3.3 3.3 0 3.3 00003.2
STANDBY 0 0 0 3.3 3.2 3.2 3.3 3.3 0 0 3.2 3.3 3.3 0 3.3 00003.2
SA-MAX8000GN MAIN P.C.B
.
IC1001
IC1001
IC1002
IC1202
IC1202
IC1001
IC1001
IC1001
IC1001
IC1001
