82
14.1.6. Mic and Multi Control P.C.B.
14.1.7. SMPS P.C.B.
REF NO.
MODE 1234567891011121314
PLAY 6666666011.9 5.8 0.2 0 11.9 5.9
STANDBY 6666666011.9 5.8 0.2 0 11.9 5.9
REF NO.
MODE 12345678910111213141516
PLAY 0 0 1.6 0000001.22.10.60.61.10.63.3
STANDBY 0 0 1.6 0000001.22.10.60.61.10.63.3
SA-MAX8000GN MIC P.C.B.
IC1600
SA-MAX8000GN MULTI CONTROL P.C.B.
IC1401
REF NO.
MODE 12345678
PLAY 2.5 1.2 0.2 0 1.2 0 0.8 17.6
STANDBY 2.5 1.2 0.2 0 1.2 0 0.8 17.6
REF NO.
MODE 12345678
PLAY 0.2 0.1 00000.317.6
STANDBY 0.2 0.1 00000.317.6
REF NO.
MODE 12345678
PLAY 6 1 2.4 17.4 324 - 0 0
STANDBY 6 1 2.4 17.4 324 - 0 0
REF NO.
MODE 12345678910111213141516
PLAY 17.6 5.5 2.2 2.5 4.2 0.9 0 0 0 10.2 4.4 0 0 206.4 196.7 204.8
STANDBY 17.6 5.5 2.2 2.5 4.2 0.9 0 0 0 10.2 4.4 0 0 206.4 196.7 204.8
REF NO.
MODE K A R
PLAY 2.3 0 2.4
STANDBY 2.3 0 2.4
REF NO.
MODE K A R
PLAY -28 -40.1 -36.9
STANDBY -28 -40.1 -36.9
REF NO.
MODE E C B E C B E C B E C B E C B
PLAY 0.3 0 0.2 0.1 0 0 17.6 17.6 16.9 0 1.7 0.3 0 0 0
STANDBY 0.3 0 0.2 0.1 0 0 17.6 17.6 16.9 0 1.7 0.3 0 0 0
REF NO.
MODE E C B E C B
PLAY 0 0.1 3.1 -41 -38.5 -41
STANDBY 0 0.1 3.1 -41 -38.5 -41
SA-MAX8000GN SMPS P.C.B.
QR1601 QR1720
IC1701
Q1101 Q1203
IC1101
IC1202
Q1402 Q1702 Q1720
IC1402
IC1501
IC1601
