Panasonic SA-PM24EB - 12.3. MAIN P.C.B. (2;2); 12.4. PANEL P.C.B.; 12.5. POWER P.C.B.

59
12.3. MAIN P.C.B. (2/2)
12.4. PANEL P.C.B.
12.5. POWER P.C.B.
REF NO.
MODE 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
CD PLAY03.33.303.303.33.3000000000000
STANDBY03.33.300003.3000000000000
REF NO.
MODE 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
CD PLAY03.300000000001.60000000
STANDBY03.300000000001.20000000
REF NO.
MODE 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100
CD PLAY000000003.3003.33.3002.22.0003.3
STANDBY 0 0 0 0 0 0 0 0 3.3 3.3 0 3.3 3.3 0 0 1.2 2.0 3.3 0 3.3
REF NO.
MODE 123456 ECB ECB ECB
CD PLAY 0 3.3 0 0 3.3 0 0 0 0.7 1.5 0 1.0 9.0 13.7 10.3
STANDBY 0 3.3 0 0 3.3 0 0 0 0.7 0 0.7 0 9.0 13.7 10.3
REF NO.
MODE E C B E C B
CD PLAY 3.3 0 3.3 0 0 0
STANDBY 3.3 3.3 3.3 0 0 3.3
IC800
IC800
Q750
Q801
Q650
SA-PM24EB/EG/EP MAIN P.C.B.
IC800
Q222
Q1
Q2
REF NO.
MODE 1234567891011121314151617181920
CD PLAY00001.83.31.20.81.20003.3-29.0-29.0-27.0-27.0-27.0-24.5-24.5
STANDBY00000.93.30000003.30000000
REF NO.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
CD PLAY -29.0 -24.5 -27.0 -29.5 -29.5 -29.5 -29.5 -24.5 -20.0 -24.5 -24.5 -27.5 -24.5 -27.0 -27.0 -27.0 -27.0 -27.0 -27.0 -27.0
STANDBY00000000000000000000
REF NO.
MODE 41 42 43 44
CD PLAY -27.0 -27.0 3.3 0
STANDBY 0 0 3.3 0
IC900
IC900
IC900
SA-PM24EB/EG/EP PANEL P.C.B.
REF NO.
MODE 123456789101112
CD PLAY15.20003.30000000
STANDBY000000003.3000
IC5101
SA-PM24EB/EG/EP POWER P.C.B.
