20 Terminal Function of IC’s
20.1. IC800 (RFKWMPM5EB) MICRO PROCESSOR
Pin No. Mark I/O Function
1
PCONT1 O Power Control Output 1(Pwr Sply,Active
HIGH)
2 PCONT2 O Power Control Output 2
3 FL_CS O Chip select for FL Panel
4FL DATA
OCD_SDA
O FL Data Output
5 MUTE_HP O Analog MUTE Output (L:MUTE ON)
6 FL_CLK
OCD_SCL
O FL CLK Output
On Chip Debugger Clock
7 HP_SW I Headphone detect switch input
8 MBP1 - No Connection
9 MBP2 - No Connection
10 NC - No Connection
11 MMOD I Memory mode selection
12 OSC2 (8MHz) O Main Oscillator output (8MHz)
13 OSC1 (8MHz) I Main Oscillator input (8MHz)
14 VSS - Micom GND
15 XI (32KHz) I Slow Oscillator input (32KHz)
16 XO (32KHz) O Slow Oscillator output (32KHz)
17 3.3V - 3.3V
18 Internal (1.8V) - Connect to pin 37
19 NRST I MICOM RESET PIN (L: reset)
20 USB_IRQ I USB Interrupt Request
21 MMOD0 O Switching Mode
22 TERR/FLAG I Timeout Error/Current Limitter IC
output
23 VERR/CTRL O Verify Error/Current Limitter IC input
CTRL H: Cut 5V supply L: Normal
24 USB_RST O USB Reset Pin
25 RMT I Remote Control Input
26 HALT I AC detection
27 DAB_DDOWFIC - No Connection
28 NC - No Connection
29 BLKCK I CD Subcode Block Clock Input
30 VSS O Micom GND
31 CD_MDATA O CD LSI Command Data
32 STAT I CD LSI Status Input
33 CD_MCLK O CD LSI Command Clock
34 USB_SDA I/O USB I2C Data Line
35 CD_MLD O CD LSI Command Load
36 USB_SCL I USB I2C Clock Line
37 1.8V - Power Supply (1.8V)
38 NC - No Connection
39 VSS - Micom GND
40 CLOSE_L O CD Tray Close Control (Active L)
41 OPEN_H O CD Tray Open Control (Active H)
42 CD_OPEN_SW I CD Open SW (H:Open; L:Close)
43 REST_SW I REST SW (L:Inner)
44 NC - No Connection
45 CD_RST O CD LSI Reset Ouput (L: reset)
46 NC - No Connection
47 Demo_Setting I Demo Mode Setting Input
48 MODEL_SELEC
T
I Tape Select (H: PM5)
49 PLL_DI I PLL Data Input
50 PLL_DO O PLL Data Output
51 PLL_CLK O PLL Clock
52 PLL_CE O PLL chip select
53 NC - No Connection
54 NC - No Connection
55 NC - No Connection
56 NC - No Connection
57 NC - No Connection
58 NC - No Connection
59 NC - No Connection
60 NC - No Connection
61 NC - No Connection
62 CRTIMER I/O CR TIMER
63 VSS - Micom GND
64 ASP_CLK I/O ASP Sound Processor Serial Clock
Output
65 ASP_DATA I/O ASP Sound Processor Serial Data
Output
66 NC O No Connection
67 DAB_RST - No Connection
68 DAB_TU_RST - No Connection
69 DAB_TU_SCL - No Connection
70 DAB_TU_SDA - No Connection
71 DAB_PCONT - No Connection
72 DAB_RX - No Connection
73 RDS_DATA I RDS_DATA Input
74 RDS_CLK I RDS_CLK Input
75 DAB_MODE - No Connection
76 NC - No Connection
77 NC - No Connection
78 NC - No Connection
79 NC - No Connection
80 NC - No Connection
81 NC - No Connection
82 NC - No Connection
83 NC - No Connection
84 NC - No Connection
85 NC - No Connection
86 NC - No Connection
87 NC - No Connection
88 FAN_SW O Fan Switch
89 VDD - Micom VDD +5V
90 ADM_MUTE O Amplifier MUTE Output (H:MUTE
ON)
91 VSS - GROUND
92 KEY1 I Key 1 input
93 KEY2 I Key 2 input
94 NC - No Connection
95 NC - No Connection
96 DCDET I DC Level Detection Input
97
REGION I Region Setting Input
98 VOL_JOG I Jog Input
99 NC O No Connection
100 VREF+ - A/D Converter reference voltage
+3.3V
Pin No. Mark I/O Function
