94
D5917 MA2J1110GL DIODE 1
D5918 B0BC7R5A0266 DIODE 1
D5919 B0EAKM000117 DIODE 1
D5920 MA2J1110GL DIODE 1
D5921 B0EAKM000117 DIODE 1
D5922 B0EAKM000117 DIODE 1
D5923 B0EAKM000117 DIODE 1
D5924 B0EAKM000117 DIODE 1
D5925 MA2J1110GL DIODE 1
D5927 B0BC6R8A0266 DIODE 1
D7650 MAZ8056GML DIODE 1
VARIABLE RESISTORS
VR900 EVEKE2F2524B VOLUME ENCODER 1
SWITCHES
S900 EVQ21405RJ SW POWER 1
S901 EVQ21405RJ SW REW 1
S902 EVQ21405RJ SW FF 1
S903 EVQ21405RJ SW BASS/TREBLE 1
S904 EVQ21405RJ SW STOP/-DEMO 1
S905 EVQ21405RJ SW CD PLAY/PAUSE 1
S906 EVQ21405RJ SW USB 1
S907 EVQ21405RJ SW MUSIC P. 1
S908 EVQ21405RJ SW SURROUND 1
S909 EVQ21405RJ SW FM/AM 1
S910 EVQ21405RJ SW CD OPEN/CLOSE 1
S7201 RSH1A045-1A SW REST 1
S7202 RSH1A045-1A SW CD OPEN 1
CONNECTORS
CN450 K1MP07A00011 7P CONNECTOR 1
CN451 K1MN10AA0003 10P CONNECTOR 1
CN800 K1MY06AA0124 6P CONNECTOR 1
CN802 K1MN22AA0004 22P CONNECTOR 1
CN804 K1YZ07000001 7P CABLE HOLDER 1
CN806 K1MP06A00003 5P CONNECTOR 1
CN807 K1MN22AA0004 22P CONNECTOR 1
CN900 K1MN10BA0004 10P CONNECTOR 1
CN5101 K1MP04A00003 4P CONNECTOR 1
CN5102 K1YZ06000002 6P WIRE HOLDER 1
CN5901 K1YZ04000002 4P CABLE HOLDER 1
CN5902 K1MP04A00003 4P CONNECTOR 1
CN5903 K1MP07A00011 7P CONNECTOR 1
CN7001 K1MN16B00154 16P CONNECTOR 1
CN7002 K1MN22BA0005 22P CONNECTOR 1
P1 K1KA03BA0125 3P CONNECTOR 1
P901 K1MN22BA0005 22P CONNECTOR 1
P903 K1FY104B0011 USB CONNECTOR 1
COILS AND INDUC-
TORS
L1 G2ZZ00000043 BIAS OSC COIL 1
L3 G2ZZ00000043 BIAS OSC COIL 1
L5 G0ZZ00002453 COIL 1
L7 G2BPC0000017 AM IFT COIL 1
L8 G0C101KA0029 FIXED INDUCTOR 1
L51 G2A390C00001 ANTENNA COIL 1
L200 G0C220JA0055 INDUCTOR 1
L659 J0JKB0000020 INDUCTOR 1
L804 J0JKB0000020 INDUCTOR 1
L900 G0C101JA0027 INDUCTOR 1
L900 G1C100K00019 INDUCTOR 1
L901 G0C101JA0027 INDUCTOR 1
L950 J0JBC0000019 INDUCTOR 1
L5901 ELF15N035AN LINE FILTER 1
LB321 J0JBC0000015 INDUCTOR 1
LB322 J0JBC0000015 INDUCTOR 1
Safety Ref.
No.
Part No. Part Name &
Description
QTY Remarks
TRANSFORMERS
T5901 G4CYAYY00213 TRANSFORMER 1
T5902 G4C2AAJ00005 BACK UP TRANS-
FORMER
1
COMPONENT COMBINA-
TION
Z900 B3RAC0000017 REMOTE SENSOR 1
Z5901 ERZVA5Z471 ZNR 1
CABLE HOLDERS
WH901 K1YZ04000002 4P CABLE HOLDER 1
WH902 K1YZ07000001 7P CABLE HOLDER 1
CERAMIC FILTER
CF1 J0B1075A0129 CERAMIC FILTER 1
T1 J0B4503A0069 CERAMIC FILTER 1
OSCILLATOR
X1 J0B1075A0121 CRYSTAL OSCILLATOR 1
X2 H0A750200020 CRYSTAL OSCILLATOR 1
X320 H0D433400007 CRYSTAL OSCILLATOR 1
X801 H4Z8004AA001 CRYSTAL OSCILLATOR 1
X802 H0A327200097 CRYSTAL OSCILLATOR 1
X900 H0A120500009 CRYSTAL OSCILLATOR 1
X7201 H0H169500013 CRYSTAL OSCILLATOR 1
RELAY
RL5901 K6B1AEA00003 RELAY 1
FL DISPLAY
FL900 A2BB00000166 LCD DISPLAY 1
FUSE
F5901 K5D102BLA013 FUSE 1
FUSE HOLDERS
FC5901 K3GE1ZZ00001 FUSE HOLDER 1
FC5902 K3GE1ZZ00001 FUSE HOLDER 1
FUSE PROTECTOR
FP5901 K5G502AA0002 FUSE PROTECTOR 1
JACKS
JK501 K4BC04B00123 JK SPEAKER 1
JK950 K2HC1YYA0015 JK MUSIC PORT 1
JK951 K2HC103A0024 JK HEADPHONE 1
JK5901 K2AA2B000011 AC INLET 1
CHIP JUMPERS
D400 D0GBR00JA008 0 1/16W 1
L951 D0GBR00JA008 0 1/16W 1
L952 D0GBR00JA008 0 1/16W 1
L953 D0GBR00JA008 0 1/16W 1
L954 D0GBR00JA008 0 1/16W 1
LB840 D0GBR00JA008 0 1/16W 1
LB841 D0GBR00JA008 0 1/16W 1
LB843 D0GBR00JA008 0 1/16W 1
LB845 D0GBR00JA008 0 1/16W 1
LB846 D0GBR00JA008 0 1/16W 1
LB848 D0GBR00JA008 0 1/16W 1
Safety Ref.
No.
Part No. Part Name &
Description
QTY Remarks
To Next Page
