13 Voltage Measurement & Waveform Chart
Note:
• Indicated voltage values are the standard values for the unit measured by the DC electronic circuit tester (high-impedance) with
the chassis taken as standard.
Therefore, there may exist some errors in the voltage values, depending on the internal impedance of the DC circuit tester.
• Circuit voltage and waveform described herein shall be regarded as reference information when probing defect point because it
may differ from actual measuring value due to difference of Measuring instrument and its measuring condition and product itself.
13.1. USB P.C.B.
REF NO.
MODE 1234567891011121314151617181920
CD PLAY 0.7 0.7 0.7 0 0 0 3.3 3.3 3.3 1.8 1.6 1.6 00003.33.33.30.7
STANDBY 0.7 0.7 0.7 0 0 0 3.4 3.3 3.4 1.8 1.6 1.6 00003.43.43.40.7
REF NO.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
CD PLAY 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 3.3 0.7 0
STANDBY 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7 3.4 0.7 0
REF NO.
MODE 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
CD PLAY 0.7 1.8 0.7 0 0.7 3.3 0.3 3.3 3.3 0 3.3 0.7 0 0 0.7 3.0 1.0 1.0 0 0.7
STANDBY 0.7 1.8 0.7 0 0.7 3.3 0.3 3.3 3.4 0 3.4 0.7 0 0 0.7 3.3 0 0 0 0.7
REF NO.
MODE 61 62 63 64
CD PLAY 0 1.8 0.7 3.3
STANDBY 0 1.8 0.7 3.3
SA-PM38DBEB USB P.C.B.
IC900
IC900
IC900
IC900
