Panasonic SA-PM38DBEB - Main PCB Voltage Measurements (1;2)

59
13.3. MAIN P.C.B. (1/2)
REF NO.
MODE 1234567891011121314151617181920
CD PLAY 0 0 4.5 0 4.5 4.5 4.5 4.5 4.5 4.5 4.5 4.5 4.5 4.5 4.5 4.5 4.5 0 3.3 3.3
STANDBY 0 0 0.5 0 0.5 0.5 0.5 0.5 0 0 0 0.5 0 0.5 0.5 0.5 0.5 0 0 0
REF NO.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
CD PLAY 9 4.5 4.5 4.5 0.9 4.5 4.5 4.5 4.5 4.5 4.5 4.5 4.5 4.5 4.5 0 4.5 0 0 4.5
STANDBY 0 0 0.5 0.5 0 0.5 0 0 0 0 0 0 0 0 0.5 0 0.5 0 0 0.5
REF NO.
MODE 41 42 43 44 45 46 47 48 49 50 51 52
CD PLAY 0 4.5 0 4.5 0 4.5 4.5 0 0 4.5 0 4.5
STANDBY 0 0.5 0 0.5 000000.500
REF NO.
MODE 12345
CD PLAY 7.5 7.5 0 5 1.25
STANDBY 0.5 0.5 0 0.7 1.25
REF NO.
MODE 12345
CD PLAY 5 0 1.2 3.3 5
STANDBY 0.7 0 0 0 0.7
REF NO.
MODE 12345678
CD PLAY 4.8 0 4.8 0 4.8 0 4.8 9
STANDBY 00000000
IC200
IC200
IC200
IC600
IC601
IC700
SA-PM38DBEB MAIN P.C.B.
