95
TRANSFORMERS
T5901 G4CYBYY00022 TRANSFORMER 1
T5902 G4C2AAJ00005 SUB TRANSFORMER 1
COMPONENT COMBI-
NATION
Z900 B3RAC0000017 REMOTE SENSOR 1
Z5901 ERZVA5Z471 ZNR 1
OSCILLATORS
X201 H0J245500084 CRYSTAL OSCILLA-
TOR
1
X801 H4Z8004AA001 CRYSTAL OSCILLA-
TOR
1
X802 H0A327200097 CRYSTAL OSCILLA-
TOR
1
X900 H0A120500009 CRYSTAL OSCILLA-
TOR
1
X7201 H0H169500013 CRYSTAL OSCILLA-
TOR
1
RELAY
RL5901 K6B1AEA00003 RELAY 1
FL DISPLAY
FL900 A2BB00000166 LCD DISPLAY 1
FUSE
F5901 K5D102BLA013 FUSE 1
FUSE HOLDERS
FC5901 K3GE1ZZ00001 FUSE HOLDER
FC5902 K3GE1ZZ00001 FUSE HOLDER
FUSE PROTECTOR
FP5901 K5G502AA0002 FUSE PROTECTOR 1
JACKS
JK330 K1QKB1BB0002 DAB CONNECTOR 1
JK950 K2HC103A0031 JK HEADPHONE 1
JK5101 K2HA1YYB0021 JK SPEAKER 1
JK5901 K2AA2B000011 AC INLET 1
P1 K4AD18A00001 18P CONNECTOR 1
P201 K4AD02A00001 2P CONNECTOR 1
CHIP JUMPERS
LB850 D0GBR00JA008 0 1/16W 1
LB852 D0GBR00JA008 0 1/16W 1
LB930 D0GBR00JA008 0 1/16W 1
LB951 D0GBR00JA008 0 1/16W 1
LB952 D0GBR00JA008 0 1/16W 1
LB7262 D0GBR00JA008 0 1/16W 1
LB7263 D0GBR00JA008 0 1/16W 1
LB7264 D0GBR00JA008 0 1/16W 1
W15 D0GDR00JA017 0 1/10W 1
W17 D0GDR00JA017 0 1/10W 1
W18 D0GDR00JA017 0 1/10W 1
W19 D0GDR00JA017 0 1/10W 1
W21 D0GDR00JA017 0 1/10W 1
W22 D0GDR00JA017 0 1/10W 1
W23 D0GBR00JA008 0 1/16W 1
W6000 D0GBR00JA008 0 1/16W 1
W6001 D0GDR00JA017 0 1/10W 1
W6002 D0GDR00JA017 0 1/10W 1
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
W6003 D0GBR00JA008 0 1/16W 1
W6004 D0GBR00JA008 0 1/16W 1
W6005 D0GBR00JA008 0 1/16W 1
W6006 D0GBR00JA008 0 1/16W 1
W6007 D0GDR00JA017 0 1/10W 1
W6008 D0GDR00JA017 0 1/10W 1
W6010 D0GDR00JA017 0 1/10W 1
W6011 D0GBR00JA008 0 1/16W 1
W6012 D0GBR00JA008 0 1/16W 1
W6013 D0GBR00JA008 0 1/16W 1
W6014 D0GDR00JA017 0 1/10W 1
W6015 D0GDR00JA017 0 1/10W 1
W6018 D0GBR00JA008 0 1/16W 1
W6020 D0GBR00JA008 0 1/16W 1
W6021 D0GDR00JA017 0 1/10W 1
W6022 D0GDR00JA017 0 1/10W 1
W6200 D0GDR00JA017 0 1/10W 1
W6201 D0GBR00JA008 0 1/16W 1
W7001 D0GBR00JA008 0 1/16W 1
W7002 D0GBR00JA008 0 1/16W 1
W7003 D0GBR00JA008 0 1/16W 1
W7004 D0GBR00JA008 0 1/16W 1
W7005 D0GBR00JA008 0 1/16W 1
W7006 D0GBR00JA008 0 1/16W 1
W7007 D0GBR00JA008 0 1/16W 1
W7008 D0GBR00JA008 0 1/16W 1
W7009 D0GBR00JA008 0 1/16W 1
W7010 D0GBR00JA008 0 1/16W 1
W7011 D0GBR00JA008 0 1/16W 1
W7012 D0GBR00JA008 0 1/16W 1
W7013 D0GBR00JA008 0 1/16W 1
W7014 D0GBR00JA008 0 1/16W 1
W7015 D0GBR00JA008 0 1/16W 1
W7016 D0GBR00JA008 0 1/16W 1
W7017 D0GBR00JA008 0 1/16W 1
W7018 D0GBR00JA008 0 1/16W 1
W7019 D0GBR00JA008 0 1/16W 1
W7020 D0GBR00JA008 0 1/16W 1
W7021 D0GBR00JA008 0 1/16W 1
W7024 D0GBR00JA008 0 1/16W 1
W7025 D0GDR00JA017 0 1/10W 1
W7026 D0GDR00JA017 0 1/10W 1
RESISTORS
R1 D0GA101JA023 100 1/16W 1
R2 D0GA101JA023 100 1/16W 1
R3 D0GA104JA023 100K 1/16W 1
R4 D0GA101JA023 100 1/16W 1
R5 ERJ2GE0R00X 0 1/16W 1
R6 D0GA393JA023 39K 1/16W 1
R7 D0GA102JA023 1K 1/16W 1
R8 D0GA101JA023 100 1/16W 1
R9 D0GA101JA023 100 1/16W 1
R10 D0GA101JA023 100 1/16W 1
R11 D0GA101JA023 100 1/16W 1
R12 D0GA101JA023 100 1/16W 1
R13 D0GA103JA023 10K 1/16W 1
R14 D0GA103JA023 10K 1/16W 1
R15 D0GA103JA023 10K 1/16W 1
R16 D0GA103JA023 10K 1/16W 1
R17 D0GA103JA023 10K 1/16W 1
R18 ERJ2GEJ100X 10 1/16W 1
R19 ERJ2GEJ182X 1.8K 1/16W 1
R20 ERJ2GEJ182X 1.8K 1/16W 1
R21 D0GA822JA023 8.2K 1/16W 1
R22 D0GA822JA023 8.2K 1/16W 1
R23 D0GA101JA023 100 1/16W 1
R24 D0GA101JA023 100 1/16W 1
R25 D0GA101JA023 100 1/16W 1
R26 D0GA101JA023 100 1/16W 1
R27 D0GA332JA023 3.3K 1/16W 1
R28 ERJ2GEJ683X 68K 1/16W 1
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
