Cursor to the bit field, and change the value by rotating the JogDial, setting
the bit rate to the same as the receiving device. The setting is adjustable in
one bit increments from 23 to 16. If , the DA7 will output 24 bits. Then
cursor to the button, and press the ENTER button to activate the setting.
The button will toggle to .
Chapter 12
DA7 Users’ Guide
12
-
15
12
D-I/O
When the button is displayed for an area in the [DITHER]
window, the bit rate output is 24 bit. Failure to toggle the button
to will cause the default bit rate of 24 bit to be output for the
signal, regardless of the bit rate setting for the area.
