Appendix E
DA7 Users’ Guide
E
-
5
E
Cables &
Connections
AD/DA Option Card
Panasonic part # DA/DB-XLRF (DB-25 to 8 Female XLR, Length 3 meters)
and Panasonic part # DA/DB-XLRM (DB-25 to 8 Male XLR, Length 3 meters)
are recommended.
Note: Make sure to use DB-25 that are less wider than 55.5 mm (2-3/16 inches) when building cables.
Connections both CN2 and CN3 to the AD/DA card will not be able if connectors are wider than 55.5
mm.
1
14
13 25
Hot
Cold
GND
Hot
Cold
GND
Hot
Cold
GND
Hot
Cold
GND
Hot
Cold
GND
Hot
Cold
GND
Hot
Cold
GND
Hot
Cold
GND
CH 8
CH 7
CH 6
CH 5
CH 4
CH 3
CH 2
CH 1
IN
1
2
3
Hot
Cold
GND
XLR(Female)
Maximum Width
55.5 mm
Maximum Width
55.5 mm
DB-25 (Male)
DB-25 (Male)
XLR (Male)
XLR (Female)
AD/DA Input Cable (for CN2 Input Connector)
AD/DA Output Cable (for CN3 Output Connector)
1
14
13 25
Hot
Cold
GND
Hot
Cold
GND
Hot
Cold
GND
Hot
Cold
GND
Hot
Cold
GND
Hot
Cold
GND
Hot
Cold
GND
Hot
Cold
GND
CH 8
CH 7
CH 6
CH 5
CH 4
CH 3
CH 2
CH 1
OUT
12
3
Hot
Cold
GND
XLR(Male)
