Parker AC10 series

Function
Code
Function Denition Setting Range Mfr’s Value Change
F423 AO1 output range
0: 0-5V
1: 0-10V or 0-20mA
2: 4-20mA
1 √
F424
AO1 lowest
corresponding freq
0.0-F425 Hz 0.05 √
F425
AO1 highest
corresponding freq
F424-F111 Hz 50.00 √
F426 AO1 output comp 0-120 100 √
F427 AO2 output comp 0: 0-20mA 1: 4-20mA 0 √
F428
AO2 lowest corresponding
freq (Hz)
0.0-F429 0.05 √
F429
AO2 highest
corresponding freq (Hz)
F428-F111 50.00 √
F430 AO2 output comp (%) 0-120 100 √
F431
AO1 analog output
signal selecting
0: Running frequency
1: Output current
2: Output voltage
3: Analog AI1
4: Analog AI2
6: Output torque
7: Given by PC/PLC
8: Target frequency
F432
AO2 analog output
signal selecting
F433
Corresponding current
for full range of external
voltmeter
0.01-5.00 times of
rated current
F434
Corresponding current
for full range of external
ammeter
F435-
F436
Reserved
F437 Analog lter width 1-100
F438-
F459
Reserved
F460 AI1channel input mode
0: Straight line mode
1: User dened input
mode
F461 AI2 channel input mode
0: Straight line mode
1: User dened input
mode
F462-
F473
AI1 and AI2 user dened
input table
N/A
10-11 Parameter List and Default Settings
