Parker AC10 series

Function
Code
Function Denition Setting Range
Mfr’s
Value
Change
F700
Selection of terminal
free stop mode
0: Immediate free stop (coast
stop);
1: Delayed free stop (coast stop)
0 √
F701
Delay time for free
stop (coast stop)
and programmable
terminal action
0.0-60.0s 0.0 √
F702 Fan control mode
0: Controlled by temperature
1: Run when inverter is powered
on
2: Controlled by running status
2 √
F703 Reserved
F704
Inverter Overload pre-
alarm Setpoint (%)
50~100 80 X
F705
Motor Overload pre-
alarm Setpoint (%)
50~100 80 X
F706
Inverter Overloading
Setpoint (%)
120-190 150 X
F707
Motor Overloading
Setpoint (%)
20-100 100 X
F708 Trip 1 Type (Newest)
Setting range:
2: Over current (OC)
3: Over voltage (OE)
4: Input phase loss (PF1)
5: Inverter overload (OL1)
6: Under voltage (LU)
7: Overheat (OH)
8: Motor overload (OL2)
11: External malfunction (ESP)
12: Current fault before running
(Err3)
13. Studying parameters without
motor (Err2)
15: Current sampling fault (Err4)
16: Over current 1 (OC1)
17: Output phase loss (PF0)
18: Analog disconnected (Aerr)
23: PID parameters set wrong (Err5)
45: Communication Timeout (CE)
46: Flycatching fault (FL)
49: Watchdog fault (Err6)
67: Overcurrent (OC2)
D
F709 Trip 2 Type
D
F710 Trip 3 Type
D
Parameter List and Default Settings
10-14
