Parker Compumotor APEX615 Series

52 APEX615n Installation Guide
2.720
(69.0)
2.11 ± 0.004
(53.6 ± 1.0)
2.76
+.06
-.00
(70.0
+1.5
-0.0
)
2.76
+.06
-.00
(70.0
+1.5
-0.0
)
.07 (1.8)
ø
.228 (
ø
5.80) THRU
(4) HOLES EQ. SPACED ON
ø
2.953 (
ø
75.00) B.C.
1.18 ± .02
(30.0 ± .5)
.551
+.0003
-.0001
(14.00
+.008
-.003
)
6.48
(164)
.093
(2.36)
.375
(9.54)
.79 MIN
(20.0)
9.61
(244.2)
-A-
.0014
A 0.003 TIR
A .003 TIR
(.08)
(.035)
(.08)
2.362
+0.0005
-0.0003
(60.00 )
+0.012
-0.007
1.53
(38.9)
BRAKE OPTION
.433 (11.00)
.429 (10.90)
.197 (5.00)
.196 (4.97)
KEYWAY DETAIL
.433 (11.00)
Dimensions in inches (mm)
Tolerances unless
otherwise specified:
.XXX ±.005
.XX ±.010
.X ±.030
Angles ±1°
APEX604 Dimensions
