APEX615n Installation Guide
General Specifications
Parameter Specification
Input Power
Voltage Range........................................................... APEX6151: 85-252VAC (1-phase)
APEX6152: 205-252 VAC (1- or 3- phase)
APEX6154: 205-252 VAC (1- or 3- phase)
Frequency Range..................................................... 47-66 Hz
Current (max. cont.)................................................. APEX6151: 14A (rms) at 120 VAC; 10A (rms) at 240 VAC
APEX6152: 8A (rms) 3- phase
APEX6154: 15A (rms) 3- phase
Power (max. cont.)................................................... APEX6151: 2.4 KVA
APEX6152: 3.3 KVA
APEX6154: 6.2 KVA
Fuses......................................................................... No internal fuses. Recommended external fuse:**
APEX6151: 120 VAC Operation: 25A slow blow (Littelfuse #326-025 or equivalent)
240 VAC Operation: 15A slow blow (Littelfuse #326-015 or equivalent)
APEX6152: 12A slow blow (Littelfuse #326-012 or equivalent)
APEX6154: 20A slow blow (Littelfuse #326-020 or equivalent)
Isolation Transformer............................................... Not required
*For operation from single phase power, derate system performance according to motor
size and total system performance.
**The actual input power and current is a function of the motor's operating point (speed and
torque) and the duty cycle. You can de-rate the fuses by scaling the above numbers by your
actual requirements. The numbers above reflect the servo motor and drive operating at
rated speed and rated torque at 100% duty.
Output Power
Voltage ...................................................................... APEX6151: 170-340 VDC (nominal), 420 VDC (maximum)
APEX6152: 340 VDC (nominal), 420 VDC (maximum)
APEX6154: 340 VDC (nominal), 420 VDC (maximum)
Frequency................................................................. APEX6151: 0-400 Hz fundamental (15 KHz PWM)
APEX6152: 0-400 Hz fundamental (8 KHz PWM)
APEX6154: 0-400 Hz fundamental (8 KHz PWM)
Current (max. cont.)................................................. APEX6151: 8A continuous per phase sinusoidal (5.66A rms)
16A peak per phase sinusoidal (11.31A rms)
APEX6152: 12A continuous per phase sinusoidal (8.5A rms)
24A peak per phase sinusoidal (17.0A rms)
APEX6154: 20A continuous per phase sinusoidal (14.14A rms)
40A peak per phase sinusoidal (28.3A rms)
Environmental
Operating Temperature ........................................... 32 to 122°F (0 to 50°C)
Storage Temperature............................................... -22 to 185°F (-30 to 85°C)
Humidity.................................................................... 0 to 95% non-condensing
Performance
Position Range.......................................................... ±2,147,483,648 steps
Velocity Range.......................................................... 0.001-200 counts/sec
Acceleration Range.................................................. 0.001-999.9999 units/sec
2
Velocity Repeatability .............................................. ±0.02% of set rate
Velocity Accuracy .................................................... ±0.02% of maximum rate
PositionalRepeatability ............................................ ±0.088 degrees, unloaded
Positional Accuracy ................................................. Resolver Accuracy: ±10 arc minutes
Resolver-to-Digital Converter Accuracy: ±10 arc minutes
Positional Resoluton................................................. Resolver-to-Digital Converter Resolution: 4096 counts/rev
Motion Trajectory Update Period............................ Default is 1.7 ms (depends on SSFR value)
Servo Sampling Update Period............................... Default is 400 µs (depends on SSFR value)
System Update Period............................................. Default is 1.7 ms (depends on SSFR value)
