APEX615n Installation Guide
What You Should Have
(ship kit)
Part Name Part Number
If an item is missing,
call the factory (see
phone numbers on
inside front cover).
One of the following line items:
APEX615n standard product (with ship kit)............................................................... APEX615n
APEX615n standard product (with ship kit)............................................................... APEX615n
APEX615n standard product (with ship kit)............................................................... APEX615n
The part number will say APEX6151, APEX6152, or APEX6154, depending on which
version you ordered.
Ship kit: 3-pin Plug (one included: COM 1 connector)............................................ 43-009055-01
5-pin Plug (one included: COM 2 connector)............................................ 43-005561-01
9-pin Plug (one included: Ext. Encoder Input connector).......................... 43-008755-01
4-pin Plug (one included: Limits connector).............................................. 43-005560-01
11-pin Plug (one included: Auxiliary connector)......................................... 43-008885-01
13-pin Plug (two included: Drive Aux. and Resolver connectors)............. 43-013802-01
7-pin Plug (one included: Encoder Output connector).............................. 43-013801-01
7-pin Plug (one included: Power connector)............................................. 43-013575-01
8-pin Plug (one included; Motor connector).............................................. 43-014533-01
Cable, Jumper (2 included, for AC power connector).................................. 71-015237-01
22 AWG, .2" c/c, Yellow (4 included, Jumper Wires)................................... 44-011061-01
22 AWG, .8" c/c, White (1 included, Jumper Wire)....................................... 44-015830-01
This installation guide (
APEX615n Installation Guide
)................................... 88-016148-01
6000 Series Software Reference
.................................................................... 88-012966-01
6000 Series Programmer’s Guide
.................................................................. 88-014540-01
Motion Architect diskettes: Disk 1........................................................ 95-013070-01
Disk 2........................................................ 95-013070-02
Options/Accessories Part Number
APEX Series Motor (brushless motor with resolver)................................ APEX602-MO, APEX603-MO
Motor Cable: (For APEX602, APEX603 Motors)................................. 71-013863-xx
Resolver Cable (For APEX602, APEX603 Motors)................................. 71-013862-xx
Resolver Cable (For APEX602, APEX603 with brake)........................... 71-014082-xx
SM Series Motor (brushless motor with resolver).................................... SM-231AR, SM-232AR, SM-233BR
Resolver Cable (for SM-231AR, SM-232AR, SM-233BR).................... 71-015019-yy
Motor Cable: (for SM-231AR, SM-232AR, SM-233BR).................... 71-015078-yy
Cable Kit: (Resolver & Motor Cables for SM-23 motors)...................... 23RS CABLE-10, 23RS CABLE-25
NOTES: Cable lengths, represented by “xx,” can be NC (no cable), 25, 50, or 100 feet.
Cable lengths, represented by “yy,” can be 10 or 25 feet.
