Parker Compumotor APEX615 Series User Manual

Chapter 1. Installation 55
0.9449
(Ø24.00 )
1.967 ± 0.02
(50.0 ± 0.5)
0.14 (3.50)
0.71 (18.0)
1.457 (37.00) min.
A 0.004 TIR
A 0.004 TIR
(0.10)
0.3932 (9.987)
0.3922 (9.962)
5.006 (127.15)
5.004 (127.10)
5.103 (129.62)
5.101 (129.57)
M5 X 0.8 Tap X 0.55 (14.0) Min. DP. (4) holes
equally spaced on 6.457 (164.0) Diameter B. C.
+0.0003
-0.0002
0.0016
-A-
Ø.433 (Ø11.00 ) Dia. thru four holes equally
spaced on Ø6.496 (Ø165.00) Dia. B.C.
Resolver and
Thermostat
Receptacle
Motor
Receptacle
5.23 ±0.08
(132.9 ±2.0)
3.93
(99.8)
5.59
(142.00 )
KEYWAY DETAIL
+3.3
-0.0
0.69 (17.5)
+0.009
-0.004
+0.13
-0.00
(0.10)
(0.040)
+0.0006
-0.0004
+0.014
-0.011
5.118
(130.00 )
Motor
APEX635
APEX640
A Max
11.78 (299.2)
14.48 (367.8)
B ± 0.08 (2.0)
5.47 (139.0)
8.17 (207.6)
Dimensions in inches (mm)
B
A
Max.
0.3149 (8.000)
0.3135 (7.964)
0.787 (20.00)
0.780 (19.80)
BRAKE OPTION
ADD TO
MAX LENGTH
1.91
(48.5)
APEX635, and 640 Dimensions
