Pendulum CNT-90 Series Programmer's Handbook

8-104 Command Reference
:SOURce :PULSe :PERiod CNT-91
8 <Numeric value>
Set Pulse Period
The pulse generator time parameters are activated when the output type is config
-
ured to PULSe using the :OUTPut command. See page 8-85.
Parameter: <Numeric value> = a number between 20
*
10
-9
and 2 s in 10 ns increments.
:SOURce :PULSe :WIDTh CNT-91
8 <Numeric value>
Set Pulse Width
The pulse generator time parameters are activated when the output type is config-
ured to PULSe using the :OUTPut command. See page 8-85.
Parameter: <Numeric value> = a number between 10
*
10
-9
and <2 s in 10 ns increments.
