8-128 Command Reference
*CLS
Clear Status Command
The *CLS common command clears the status data structures by clearing all event
registers and the error queue. It does not clear enable registers and transition fil
-
ters. It clears any pending *WAI,*OPC, and *OPC?.
Example:
Send ®
*CLS
Complies with standards: IEEE 488.2 1987.
*DDT
8<arbitrary block>
Define Device Trigger
Sets or queries the command that the device will execute on receiving the GET in-
terface message or the *TRG common command.
The currently supported DDTs are:
Example:
Send ®
*DDT8#19INIT;*OPC
*RST condition:
#215ARM:LAY2;:FETC? in native mode and #14INIT in compatible mode
Complies with standards: IEEE 488.2 1987.
1. #14INIT 4. #15READ?
2. #19INIT;*OPC 5. #215ARM:LAY2;:FETC?
3. #15FETC? 6. #18ARM:LAY2
