Pendulum CNT-90 Series User Manual

Performance Check
Key(s)
Display
Notes
P/F
STANDBY
Red standby LED On (Key common to ON)
Off
ON
Backlight On
Red standby LED Off (Key common to
STANDBY)
INPUT A
Input A:
Menu for setting Slope, Coupling, Impedance etc.
Man
Trig
Menu for entering numeric values in V or mV
Trig: xy mV
0.123V
Trig: 0.123 V
◄ (5 times)
Trig: _ V
4.567
Trig: 4.567 V
◄ (5 times)
Trig: _ V
8.9
Trig: 8.9 V
±
Trig: -8.9 V
mV
Trig: -8.9 mV
V
Trig: -8.9 V
AUTOSET
Menu disappears
INPUT B
Input B:
Menu for setting Slope, Coupling, Impedance etc.
SETTINGS
Settings:
Menu for setting Meas Time, Hold-Off, Ref.
Source etc.
ENTER
Meas Time: 200 ms
▲
Meas Time: 500 ms
▼
Meas Time: 200 ms
EXIT/OK
Settings:
Menu for setting Meas Time, Hold-Off, Ref.
Source etc.
EXIT/OK
Menu disappears
MATH/LIM
Math/Limit:
Menu for selecting post-processing formula and alarm
limit
USER OPT
User options:
Menu for Calibration, Memory Management, Interface
etc.
CANCEL
Menu disappears
At upper right corner
HOLD/RUN
Hold
HOLD/RUN
Hold disappears
Menu for selecting measurement function
MEAS FUNC
Measure function:
Cursor position marked by text inversion
►
Period
ENTER
Single A
EXIT/OK
Menu disappears
Period Single A: at upper left corner
STAT/PLOT
Period Single A
Aux parameters: Max, Min, P-P, Adev, Std
USER MANUAL ● CNT 9x Series ● Rev.22 February 2020
7-4
