Pentax DigiBino DB100 User Manual

65
Binoculars
Magnification : 7 x
Effective diameter of objective lens:
17 mm x 14 mm
Real field of view : 7.1˚
Prism type : Roof prism
Focusing method : Eyepiece lens sliding method
Focusing range : 2 m to ∞ (infinity)
Diopter adjustment range:
–5 m
-1
to +3 m
-1
(Dptr) both left
and right eyepiece lenses with
index on right eyepiece
CCD
File Formats : JPEG (Exif 2.1), DCF
Image Quality : Best, Better, and Good
Focusing method : Binoculars synchronization
(2 m to ∞ (infinity))
Storage Media : Built-in memory 16 MB
(when Best is selected: Approx. 100)
CCD/Recorded Pixels:
1/3 inches
Effective pixels 0.8 megapixel
Total pixels 0.85 megapixel
Progressive method
Best: 1024 x 768 pixels
Better: 1024 x 768 pixels
Good: 640 x 480 pixels
Taking Lens : Pentax 37 mm F4
(Equivalent to 280 mm in 35 mm format)
Scope : 8.3˚ (Visual field rate: 85%)
Digital Zoom : 1.6x (Equivalent to 450 mm in
35 mm format), 3.2x
Appendix
Main Specifications
White Balance : TTL full automation
Exposure Control : TTL automatic program
Shutter Speed : Approx. 1/8000 sec. to 1/30 sec.
CCD electronic shutter
Sensitivity : ISO 100 to 1600, Auto
Continuous Shooting:
5 shots/per second x 10 shots
Introduction Method to CCD:
3 lens methods including the
taking lens
LCD
1.6 inch. D-TFD color LCD
(with backlight)
Others
Tripod socket : Included
Interface : Data input/output terminal (USB),
Video output terminal
Power Sources : Size AA alkaline batteries (2), Size
AA nickel hydride (NiMH) batteries
(2), CR-V3 lithium battery pack (1)
Dimensions : 127 (W) x 44 (H) x 69 (D) mm
(5.0 x 1.7 x 2.7 inches)
Weight : 255 g (9.0 oz.) (without batteries)
Accessories : USB cable, Video cable, Size AA
alkaline batteries (2), Software
CD-ROM, Soft case, Strap,
Warranty card, Operating Manual
(this manual)
