Pepwave HD2 User Manual

Country
● If a North American region is selected, RF channels 1 to 11 will be available and
the maximum transmission power will be 26 dBm (400 mW).
● If European region is selected, RF channels 1 to 13 will be available. The
maximum transmission power will be 20 dBm (100 mW).
NOTE: Users are required to choose an option suitable to local laws and regulations.
Per FCC regulation, the country selection is not available on all models marketed in US.
All US models are fixed to US channels only.
Preferred
Frequency
These buttons determine the frequency at which access points will attempt to broadcast.
This feature will only work for APs that can transmit at both 5.4GHz and 5GHz
frequencies.
Protocol
This section displays the 2.4 GHz protocols your APs are using.
Channel Width
There are three options: 20 MHz, 20/40 MHz, and 40 MHz. With this feature enabled, the
Wi-Fi system can use two channels at once. Using two channels improves the
performance of the Wi-Fi connection.
Channel
This drop-down menu selects the 802.11 channel to be utilized. Available options are
from 1 to 11 and from 1 to 13 for the North America region and Europe region,
respectively. (Channel 14 is only available when the country is selected as Japan with
protocol 802.11b.) If Auto is set, the system will perform channel scanning based on the
scheduled time set and choose the most suitable channel automatically.
Auto Channel
Update
Indicate the time of day at which update automatic channel selection.
Output Power
A
This drop-down menu determines the power at which the AP under this profile will
broadcast. When fixed settings are selected, the AP will broadcast at the specified power
level, regardless of context. When Dynamic settings are selected, the AP will adjust its
power level based on its surrounding APs in order to maximize performance.
The Dynamic: Auto setting will set the AP to do this automatically. Otherwise, the
Dynamic: Manual setting will set the AP to dynamically adjust only of instructed to do
so. If you have set Dynamic:Manual, you can go to AP>Toolbox>Auto Power Adj. to
give your AP further instructions.
If you click the Boost checkbox, the AP under this profile will transmit using additional
power. Please note that using this option with several APs in close proximity will lead to
increased interference.
Client Signal
Strength
Threshold
A
This field determines that maximum signal strength each individual client will receive.
The measurment unit is megawatts.
Max number of
Clients
A
This field determines the maximum clients that can be connected to APs under this
profile.
Management
This field specifies the VLAN ID to tag to management traffic, such as AP to AP
controller communication traffic. The value is 0 by default, meaning that no VLAN tagging
http://www.peplink.com
150
Copyright @ 2017 Pepwave

Pepwave HD2 Specifications

General

Category	Network Router
Model	Pepwave HD2
WAN Ports	2
LAN Ports	4
Cellular Modems	2
Throughput	400 Mbps
Load Balancing	Yes
VPN	Yes
GPS	Yes
Wireless Standards	802.11a/b/g/n/ac
Ethernet Ports	4
Firewall	Yes
Cellular Connectivity	3G/4G LTE
VPN Support	IPsec, PPTP, L2TP
