will be applied. NOTE: change this value with caution as alterations may result in loss of
connection to the AP controller.
Choose from the schedules that you have defined in System>Schedule. Select the
schedule for the integrated AP to follow from the drop-down menu.
This drop-down menu provides the option to send beacons in different transmit bit rates.
The bit rates are 1Mbps, 2Mbps, 5.5Mbps, 6Mbps, and 11Mbps.
This drop-down menu provides the option to set the time between each beacon send.
Available options are 100ms, 250ms, and 500ms.
This field provides the option to set the frequency for beacon to include delivery traffic
indication messages (DTIM). The interval unit is measured in milliseconds.
This field provides the option to set the minimum packet size for the unit to send an RTS
using the RTS/CTS handshake. Setting 0 disables this feature.
Fragmentation
Threshold
A
Determines the maximum size (in bytes) that each packet fragment will be broken down
into. Set 0 to disable fragmentation.
Distance/Time
Converter
A
Select the distance you want your Wi-Fi to cover in order to adjust the below parameters.
Default values are recommended.
This field provides the option to modify the unit wait time before it transmits. The default
value is 9μs.
This field provides the option to set the wait time to receive acknowledgement packet
before doing retransmission. The default value is 48μs.
With this feature enabled, throughput will be increased by sending two or more data
frames in a single transmission.
This field is only available when Frame Aggregation is enabled. It specifies the frame
length for frame aggregation. By default, it is set to 50000.
A
- Advanced feature. Click the button on the top right-hand corner to activate.
