Pepwave HD2 User Manual

Card
3G/2G
This drop-down menu allows restricting cellular to particular band. Click the button to
enable the selection of specific bands.
Authentication
Choose from PAP Only or CHAP Only to use those authentication methods exclusively.
Select Auto to automatically choose an authentication method.
Data Roaming
This checkbox enables data roaming on this particular SIM card. Please check your service
provider’s data roaming policy before proceeding.
Operator
Settings
This setting applies to 3G/EDGE/GPRS modems only. It does not apply to EVDO/EVDO Rev.
A modems. This allows you to configure the APN settings of your connection. If Auto is
selected, the mobile operator should be detected automatically. The connected device will be
configured and connection will be made automatically. If there is any difficulty in making
connection, you may select Custom to enter your carrier’s APN, Login, Password, and Dial
Number settings manually. The correct values can be obtained from your carrier. The default
and recommended setting is Auto.
APN / Login
/ Password /
SIM PIN
When Auto is selected, the information in these fields will be filled automatically. Select
Custom to customize these parameters. The parameter values are determined by and can be
obtained from the ISP.
Bandwidth
Allowance
Monitor
Check the box Enable to enable bandwidth usage monitoring on this WAN connection for each
billing cycle. When this option is not enabled, bandwidth usage of each month is still being
tracked but no action will be taken.
Action
If email notification is enabled, you will be notified by email when usage hits 75% and 95% of
the monthly allowance. If Disconnect when usage hits 100% of monthly allowance is
checked, this WAN connection will be disconnected automatically when the usage hits the
monthly allowance. It will not resume connection unless this option has been turned off or the
usage has been reset when a new billing cycle starts.
Start Day
This option allows you to define which day of the month each billing cycle begins.
Monthly
Allowance
This field is for defining the maximum bandwidth usage allowed for the WAN connection each
month.
http://www.peplink.com
69
Copyright @ 2017 Pepwave

Pepwave HD2 Specifications

General

Category	Network Router
Model	Pepwave HD2
WAN Ports	2
LAN Ports	4
Cellular Modems	2
Throughput	400 Mbps
Load Balancing	Yes
VPN	Yes
GPS	Yes
Wireless Standards	802.11a/b/g/n/ac
Ethernet Ports	4
Firewall	Yes
Cellular Connectivity	3G/4G LTE
VPN Support	IPsec, PPTP, L2TP
