Sewing
37
10.03 Creating / altering seam patterns
10
.03.01 Creating a seam pattern in the "teach in mode"
The "teach in" function is particularly suitable for creating completely new seam patterns. For
this method the seam pattern is stored directly in the machine memory by sewing the seam
sections. Below is an example of how to create a seam pattern
Seam section 1
Stitches: 32
Stitch length: 2,2 mm
Speed: 2200 min
-1
Turn: 23 mm
Seam section 2
Stitches: 7
Stitch length: 2,2 mm
Speed: 2200 min
-1
Turn: 10 mm
Seam section 3
Stitches: 66
Stitch length: 2,2 mm
Speed: 2200 min
-1
Seam section 4
Stitches: 5
Theoretical stitch length: 1,2 mm
Actual stitch length: 8,0 mm
Turn: 1500 min
-1
Seam section 5
Stitches: 35
Stitch length: 2,2 mm
Speed: 2200 min
-1
Turn: 23 mm
Switch on the machine
Activate mechanic level "b", see Chapter 12.12.01 Selecting the user level.
●
●
If necessary switch on the programmed sewing mode (LED in the key is illuminated).
Press the +/- key (P) to select the desired program number (e.g. 10).
Press the +/- key (S) top set the value at "0".
Press the +/- key (L) to limit the number of seam sections (e.g. 5).
Activate the top line of the display (LED in the key is illuminated).
Press the +/- key (D) to select the desired stitch length value (e.g. 2.2 mm).
Call up the "teach in mode". (LED in the key fl ashes.)
Press the +/- key (A) to select the desired speed (e.g. 2200).
Insert the workpiece, see Chapter 9.09 Inserting the workpiece.
●
●
●
●
●
●
●
●
●
SL 2.2mm
3 3 3 3 10 0 5
