Installation and commissioning
21
Fig. 8 - 01
1
1
2
2
Loosen screws 1 and 2 and set the table height as required.
Firmly tighten screw 1.
Set the required pedal position and tighten screws 2.
●
●
●
8 Installation and commissioning
The machine must only be installed and commissioned by qualifi ed personnel!
All relevant safety regulations must be strictly adhered to!
If the machine is delivered without a table, be sure to use a stand and table top
that can hold the weight of the machine with its motor.
It is very important to ensure that the stand of the machine is fi rm and steady,
also during sewing.
8.01 Installation
The site where the machine is installed must be provided with suitable connections for the
electric current, see Chapter 3 Specifi cations.
It must also be ensured that the standing surface of the machine site is fi rm and horizontal,
and that suffi cient lighting is provided.
For packing reasons the table top is in the lowered position. The table height
is adjusted as described below.
8.01.01 Adjusting the table height
