Sewing
41
10.03.02 Altering seam patterns
If a seam pattern has been created in the "teach in mode", minor corrections are usually
necessary. These can be made as described below.
Switch on the machine.
Activate mechanic level "b", see Chapter 12.12.01 Selecting the user level.
●
●
Select the program number of the seam pattern, which is to be altered (e.g. 10), by
pressing the +/- key (P).
If necessary, alter the stitch length, see Chapter 9.06 Entering the stitch length.
If necessary alter the start and end backtacks, see Chapter 9.07 Entering the start and
end backtacks.
Press the +/- key (S) to select the section of the seam pattern, which is to be altered
(e.g. 2).
●
●
●
●
SL 2.2mm
3 3 3 3 10 0 5
If necessary, alter the number of stitches for the current seam section by pressing the
+/- key (L).
Since each alteration affects the subsequent seam sections, these must also be
corrected!
●
SL 2.2mm 10mm
2200 10 2 7
