Adjustment
89
12.12.03 List of parameters
Group
Parameter
Description
User level
Setting range
Set value
1 105 Seam start speed B,C 300 - 1500 1000
110 Seam end speed B,C 300 - 1500 1000
116 Soft start stitches B,C 0 - 30 0
117 Speed for soft start stitches B,C 30 - 1000 400
3 382 Switching threshold of the analog input for
the thread monitor
B,C 0 - 100 15
387 Output Ax (motor running) is activated
1 = with pedal 1D (motor running)
0 = with pedal 1 (lower presser foot)
B,C 0 - 1 1
4 407 Cable fault detection on speed control unit
1 = on; 0 = off
B,C 0 - 1 1
452 Input "operation lock"
1 = on; 0 = off (no function)
B,C 0 - 1 1
5 521 Needle position if sewing stop before seam end
1 = needle position "2" (take-up lever raised);
0 = needle position "1" (lowered)
B,C 0 - 1 1
538 Tacting output Ax (thread tension release)
0 = 100% power up
B,C 10 - 50 30
6 605 Actual value on display
1 = on; 0 = off
B,C 0 - 1 0
606 Speed level 1 (min.) B,C 30 - 300 180
607 Speed level 2 (max.) B,C 300 - 3500 2500
609 Cutting speed 1 B,C 60 - 300 180
615 End recognition with photo sensor
1 = from bright to dark;
0 = from dark to bright
B,C 0 - 1 1
618 Reversing after seam end
1 = on; 0 = off
B,C 0 -1 1
623 Switch on delay for reversing [ms] B,C 0 - 2000 30
660 Bobbin thread monitoring
0= without monitoring
1 = with sensor
2 = with stitch counting
A,B,C 0 - 2 0
