Service functions
74
● Operate the pedal.
The activated pedal stages are shown in setting range D.
● Call up the test for the synchronizer in the motor with the corresponding function keys.
● Turn the balance wheel and check the needle bar reference position (parameter "700").
● With the corresponding function keys, call up the speed reduction test.
The speed reduction or increase ratio status of the motor is displayed. The adjustment
is carried out with parameter "802".
● Select the test mode for the pedal with the corresponding function keys.
● With the corresponding function keys call up the display of the maximum analogue value
of the potentiometer for the stroke lift adjustment.
No Ratio
ExtSm 1
Ped: 4D
Pos: 137
Lift: 127
