3. Flatten the colored wires in the order described below.
5. Use a crimping tool to fasten the connector to the cable.
4. Insert the wires all the way into a 6P6C RJ12 Plug.
Make sure that the wires stay in the correct order.
4
RJ -12 Plug
Position NO.
RJ -11 Cable
Colored wires
1
2
3
4
5
6
5
Position 6
Position 1
Null
Null
White/orange
orange
Green
White/Green
White/brown
brown
Green
White/Green
