PHYLINK Covert Network Camera User Manual
PLC-128 series
include various mounting brackets for quick and easy installation.
The sensor unit can be mounted flat or angled on any surface, using the angled
mounting bracket. The camera can also be mounted covertly behind a thin wall,
cupboard, door and etc. With miniature size design it enables easy integration into
any hidden place.
Mounting Accessories
Local storage for storing recorded image and video.
Micro SD Card slot
Connects to the included DC 12V power adapter.
Power Connector
Reset/WPS Button
Press this button for 5 seconds to reset the camera. All settings will be restored to
factory default.
Status indicator LED
Short press this button to setup a wireless connection automatically (WPS function).
After is powered on, the indicator LED shows yellow light and quickly offMain Unit
which means the system is being started. When the indicator LED shows yellow
again, it means the system has started successfully.
The indicator LED flashes during data transfer and shows red light for WPS connection
status.
General I/O Terminal
Used to connect the external wired alarm devices like PIR sensor, gas detector, siren, etc.
Note: PLC-128P has no WPS function.
The sensor unit and main unit are connected by an 8 meter cable, providing flexibility
to place the sensor unit in one place and the main unit elsewhere.
Sensor Unit and RJ11 Cable
IMPORTANT!
The sensor unit is not approved for outdoor use. The product may only be installed
in indoor environments.
