AutoZero OFF,AutoGain OFF,AutoRange OFF, Scan Timer=0,60Hz
single
function(VDC)
NPLC
Take Time with 2000 Readings(sec)
rate(ch/s)
(Fast 4.5) 0.02
68 29.4
(Slow 4.5 & Fast 5.5) 0.1
74 27.0
(Slow 5.5 & Fast 6.5) 1
105 19.0
(Slow 6.5) 10
408 4.9
AutoZero OFF,AutoGain OFF,AutoRange OFF, Scan Timer=0,60Hz
Mix function
(VDC+2WRES)
NPLC
Take Time with 2000 Readings(sec)
rate(ch/s)
(Fast 4.5) 0.02
306 6.5
(Slow 4.5 & Fast 5.5) 0.1
318 6.3
(Slow 5.5 & Fast 6.5) 1
442 4.5
(Slow 6.5) 10
1710 1.2
How to program each channel with measurement function
Press CONFIG + SHIFT + DIGITS for scanning configuration. Use ◁ and
▷ to scroll through submenus. Press ENTER on “SET SCAN CHA”
submenu. Use ◁ and ▷ to switch from channel 1 to channel 10, and
use △ and ▽ to switch among the measurement functions. Leave an
unused channel with a blank space (----). Press ENTER when ten
channels are all defined.
How to configure scan count, scan interval and store
measurement readings
Press CONFIG + SHIFT + DIGITS for scanning configuration. Use ◁ and
▷ buttons to scroll through submenus. Press ENTER to select
“OPERATION” submenu. Use ◁ and ▷ to switch among scan count
(COUNT), scan interval (TIMER) and store (STORE) options. Then press
ENTER on your selection. Use ◁ and ▷ to move through the digits and
△ and ▽ to increase or decrease the numbers to a desired value. For
STORE option, you can select ON to instruct the meter to store the
measurement results for later retrieving or select OFF .Press ENTER to
set the value.
How to open and close the channels
Press CONFIG + SHIFT + DIGITS for scanning configuration. Use ◁ and
▷ buttons to scroll through submenus. Press ENTER on “----” when you
need to close a specific channel. Press ENTER again on “CHANNEL”. Use
