Pioneer PDP-5000EX Service Manual

PDP-5000EX
101
5678
56
7
8
C
D
F
A
B
E
Nonreplaceable parts
FHD DIGITAL Assy
PANEL SENSOR Assy
FHD MAIN Assy
Ref. No. Part Category Part No. Remarks
IC3701 4K EEPROM BR24L04FJ-W-TBB
Replaceable if backup data are to be copied to the part after
replacement
Ref. No. Part Category Part No. Remarks
IC3902 2K EEPROM BR24L02FJ-W-TBB Replaceable if the FHD DIGITAL Assy is not replaced simultaneously
Ref. No.
Part Category Part No. Remarks
IC4601 CVBS SW IC R2S11002AFT-K
IC4803 FLASH UCOM AGC1005- -PI-K The program for the microcomputer is written on it.
IC5001 64K EEPROM BR24L64F-W-TBB
IC5005 FLASH MEMORY IC AGC1012- -PI-K The program for the microcomputer is written on it.
IC5202 A/D CONVERTER AD9985KSTZ-110-K
IC5402 3D Y/C SEPA & VDEC IC UPD64015AGM-UEU-K
IC5403 VIDEO DECODER TVP5150AM1PBS-K
IC5601 RGB SW IC R2S11001FT-K
IC6203 FLASH MEMORY IC AGC1013- -PI-K The program for the microcomputer is written on it.
IC6802 2K EEPROM BR24L02FJ-W-TBB EDID data are written on it.
EDID data are written on it.
EDID data are written on it.
EDID data are written on it.
IC6803 2K EEPROM BR24L02FJ-W-TBB
Adjustment data that are specific to the Assy are written on it.
IC7003 2K EEPROM BR24L02FJ-W-TBB
IC7004 2K EEPROM BR24L02FJ-W-TBB

Pioneer PDP-5000EX Specifications

General

Depth	98 mm
Width	1282 mm
Height	750 mm
Weight	39800 g
Pixel pitch	- mm
Product color	Black
Audio (L/R) in	1
Noise reduction	Yes
RMS rated power	13 W
Display diagonal	50 \
Display brightness	1000 cd/m²
Display technology	Plasma
Power requirements	AC 110 - 240 V, 50/60 Hz
Contrast ratio (typical)	3000:1
Power consumption (standby)	0.4 W
Power consumption (typical)	420 W
