Pioneer PDP-5000EX Service Manual

PDP-5000EX
103
5678
56
7
8
C
D
F
A
B
E
7.3.2 HOW TO COPY THE BACKUP DATA (when reusing a second-hand Assy)
7.3.3 FORMATION OF A FHD DIGITAL ASSY (RE-SERVICE PART )
Command: FAJ command
(Be effective between FAY command)
Factory Menu:
PANEL INFORMATION
ETC. (+)
BACKUP DATA : NO OPRT
DIGITAL EEPROM : NO OPRT
DIGITAL EEPROM : REPAIR
(down)
(down)
(down)
(set)
(right)
(set)(5 sec)
When replacing the FHD DIGITAL Assy with one that was mounted on another product, copy the backup data,
as shown below:
Note:
If the secondhand FHD DIGITAL Assy is mounted in the product then the unit is turned on then back off again, the
data in the EEPROM on the FHD DIGITAL Assy are copied over the EEPROM in the PANEL SENSOR Assy.
Command: UAJ command
(Be effective between FAY command)
Factory Menu:
PANEL INFORMATION
ETC. (+)
BACKUP DATA : NO OPRT
DIGITAL EEPROM : NO OPRT
DIGITAL EEPROM : DELETE
(down)
(down)
(down)
(set)
(right)
(set)(5 sec)
When adjusting the FHD DIGITAL Assy that is mounted on one product so that it can be mounted on another product,
proceed as follows:
How to adjust the FHD DIGITAL Assy that is mounted on one product so that it can be mounted
on another product

Pioneer PDP-5000EX Specifications

General

Depth	98 mm
Width	1282 mm
Height	750 mm
Weight	39800 g
Pixel pitch	- mm
Product color	Black
Audio (L/R) in	1
Noise reduction	Yes
RMS rated power	13 W
Display diagonal	50 \
Display brightness	1000 cd/m²
Display technology	Plasma
Power requirements	AC 110 - 240 V, 50/60 Hz
Contrast ratio (typical)	3000:1
Power consumption (standby)	0.4 W
Power consumption (typical)	420 W
