Pioneer PDP-5000EX Service Manual

PDP-5000EX
160
1234
1234
C
D
F
A
B
E
9.3.10 QNG
QNG: Returning data (logs keep on Main microcomputer) on shutdown of the main microcomputer.
• Details on the NG data and subcategory
Data Cause of Shutdown Remarks
0 Normal
1 Communication failure of Module microcomputer
2 3-wire Serial Communication failure of Main microcomputer. Subcategory ⇒ 1
3 IIC Communication failure of Main microcomputer Subcategory ⇒ 2
4 Communication failure of Main microcomputer & Unknown Error
5 Fan stopped
6 Abnormally high temperature of MTB section
8 Abnormally in ASIC power (POWER) Subcategory ⇒ 3
B Short circuit the speaker
Command Effective Operation Modes Function Remarks
QNG Continually Status output Return data : 101 byte
Order Data Size Context
ECO 3 byte QNG only
1 Latest NG data 1 byte 0
2 Data of subcategory for the latest NG 1 byte 0
3 Data of Hour meter for the latest NG 7 byte 0000000
4 Data of temperature (TEMP2) for the latest NG 3 byte 000
5 2nd latest NG data 1 byte 0
6 Data of subcategory for the 2nd latest NG 1 byte 0
7 Data of Hour meter for the 2nd latest NG 7 byte 0000000
8 Data of temperature (TEMP2) for the 2nd latest NG 3 byte 000
9 3rd latest NG data 1 byte 0
10 Data of subcategory for the 3rd latest NG 1 byte 0
11 Data of Hour meter for the 3rd latest NG 7 byte 0000000
12 Data of temperature (TEMP2) for the 3rd latest NG 3 byte 000
13 4th latest NG data 1 byte 0
14 Data of subcategory for the 4th latest NG 1 byte 0
15 Data of Hour meter for the 4th latest NG 7 byte 0000000
16 Data of temperature (TEMP2) for the 4th latest NG 3 byte 000
17 5th latest NG data 1 byte 0
18 Data of subcategory for the 5th latest NG 1 byte 0
19 Data of Hour meter for the 5th latest NG 7 byte 0000000
20 Data of temperature (TEMP2) for the 5th latest NG 3 byte 000
21 6th latest NG data 1 byte 0
22 Data of subcategory for the 6th latest NG 1 byte 0
23 Data of Hour meter for the 6th latest NG 7 byte 0000000
24 Data of temperature (TEMP2) for the 6th latest NG 3 byte 000
25 7th latest NG data 1 byte 0
26 Data of subcategory for the 7th latest NG 1 byte 0
27 Data of Hour meter for the 7th latest NG 7 byte 0000000
28 Data of temperature (TEMP2) for the 7th latest NG 3 byte 000
29 8th latest NG data 1 byte 0
30 Data of subcategory for the 8th latest NG 1 byte 0
31 Data of Hour meter for the 8th latest NG 7 byte 0000000
32 Data of temperature (TEMP2) for the 8th latest NG 3 byte 000
CS 2 byte 77

Pioneer PDP-5000EX Specifications

General

Depth	98 mm
Width	1282 mm
Height	750 mm
Weight	39800 g
Pixel pitch	- mm
Product color	Black
Audio (L/R) in	1
Noise reduction	Yes
RMS rated power	13 W
Display diagonal	50 \
Display brightness	1000 cd/m²
Display technology	Plasma
Power requirements	AC 110 - 240 V, 50/60 Hz
Contrast ratio (typical)	3000:1
Power consumption (standby)	0.4 W
Power consumption (typical)	420 W
