11.3 PANEL FACILITIES
7
6
8
9
11
12
13
123
4
5
1 MAIN POWER switch
Use to switch the main power of the unit on and off.
2 ON indicator
3 STANDBY indicator
4 Remote control sensor
5 Handles
6  STANDBY/ON button
7 INPUT button
8 HOME MENU button
9 ADJUST (»/«/\/|) buttons
10 VOLUME +/- buttons
11 ENTER/DISP. button
12 RETURN button
13 SCREEN SIZE button
Note
The unit's operating panel will become
inoperable if connected speakers are installed
too near the main unit.
• Main unit
