9.3 OUTLINE OF COMMANDS
9.3.1 QS1
7 Acquisition of panel statuses • • • [QS1]
The command QS1 is for acquiring data necessary for authentication of both the main unit's microcomputer and the
module's microcomputer.
Command
Format
Effective Operation
Modes
Function Remarks
[QS1] Continually To acquire data on product status Return data: 105 Byte
1: Resolution/size
3 1024∗768-42
4 1024∗768-43
5 1280∗768-50
6 1365∗768-50
7 1365∗768-60
F 1920∗1080-50
2: Generation
6G6
7G7
8G8
9G9
0 G10
3: Destination
∗ Common
A North America (Reserved)
E Europe (Reserved)
J Japan (Reserved)
16: Destination of MTB
A North America
E Europe
J Japan
18: Product type of MTB
B Integrated TV
M FHD
S System model
12: Panel type 1
P Conventional panel
F High-efficiency panel
4: Grade
∗ Common
Data Arrangement
Data
Length
Output Example
ECO 3 Byte QS1
1 Resolution/size 1 Byte F
2 Generation 1 Byte 7
3 Destination 1 Byte *
4 Grade 1 Byte *
5 Product type 1 Byte M
6 MDUcom-Boot 3 Byte 01A
7 MDUcom-PRG 8 Byte 001A_M "space × 2"
8 ASTRA-Boot 3 Byte 01A
9 ASTRA-PRG 8 Byte 001Y "space × 4"
10 SQ-VIDEO 4 Byte 001Y
11 SQ-PC 4 Byte 001Y
12 Panel type 1 1 Byte P
13 Reserved 7 Byte ∗∗∗∗∗∗∗
14 , (comma) 1 Byte
15 MTB generation 1 Byte 7
16 MTB destination 1 Byte ∗
17 MTB grade 1 Byte W
18 MTB product type 1 Byte M
19 IF microcomputer 4 Byte
20 Main microcomputer 8 Byte
21 Main microcomputer boot 4 Byte
22 Multi processor 8 Byte
23 Multi processor boot 4 Byte
24 Reserved 24 Byte
CS 2 Byte 7B
5: Product type
S System model
B Integrated TV
M Monitor
D Standard module
15, 17, 19 to 23: Product type of MTB
IF microcomputer Version of IF microcomputer
Main microcomputer Common version of Main microcomputer
Main microcomputer
boot
Boot version of Main microcomputer
Multi processor Common version of Multi processor
Multi processor boot Boot version of Multi processor
