PDP-5000EX
150
1234
1234
C
D
F
A
B
E
Command
Division
Function
command
Reception Point
Last
Memory
Only
FAY is
Effective
Remarks
U
UAJ SGL Determining the flag for the unit adjustment in "not adjusted"
¶
UP∗ SUB
To add ∗∗∗ to the adjustment value ∗∗∗ = 000 to 999
With DW0, the adjustment value is added by 10.
¶
V
VFQ S01 FNC Setting the frequency in Mask mode to VD-48 Hz
¶
Mod
¶
S02 FNC Setting the frequency in Mask mode to VD-50 Hz
¶
Mod
¶
S03 FNC Setting the frequency in Mask mode to VD-60 Hz
¶
Mod
¶
S05 FNC Setting the frequency in Mask mode to VD-72 Hz
¶
Mod
¶
S06 FNC Setting the frequency in Mask mode to VD-75 Hz
¶
Mod
¶
S13 FNC Setting the frequency in Mask mode to PC-60 Hz
¶
Mod
¶
S14 FNC Setting the frequency in Mask mode to PC-70 Hz
¶
Mod
¶
S22 FNC Setting the frequency in Mask mode to VD-50 Hz (nonstandard)
¶
Mod
¶
S23 FNC Setting the frequency in Mask mode to VD-60 Hz (nonstandard)
¶
Mod
¶
S25 FNC Setting the frequency in Mask mode to VD-72 Hz (nonstandard)
¶
Mod
¶
S26 FNC Setting the frequency in Mask mode to VD-75 Hz (nonstandard)
¶
Mod
¶
VOF ∗∗∗ ADJ Adjustment of the reference value of Vofs voltage
¶
Mod
¶
UP/DW key not effective
VOL
UP∗,
DW∗,
∗∗∗
ADJ
To adjust the volume (to be used in combination with UP∗/DW∗)
*** = 000 to 060
¶
Main
VRP ∗∗∗ ADJ Adjustment of the reference value of Vrst-p voltage
¶
Mod
¶
UP/DW key not effective
VSU ∗∗∗ ADJ Adjustment of the reference value of Vsus voltage
¶
Mod
¶
UP/DW key not effective
W
WBI S00 FNC Panel WB standard output mode: off
¶¶
S01 FNC Panel WB standard output mode: on
¶¶
X
XSB ∗∗∗ ADJ X-SUS-B ADJ
¶
Mod
¶
UP/DW key not effective
Y
YSB ∗∗∗ ADJ Y-SUS-B ADJ
¶
Mod
¶
UP/DW key not effective
YTB ∗∗∗ ADJ Y-SUSTAIL T2 ADJ
¶
Mod
¶
UP/DW key not effective
YTG ∗∗∗ ADJ Y-SUSTAIL T1 ADJ
¶
Mod
¶
UP/DW key not effective
YTW ∗∗∗ ADJ Y-SUSTAIL W ADJ
¶
Mod
¶
UP/DW key not effective
Z
ZME SGL Initializing the video EEPROM data
¶¶
ZPR SGL Initializing the setting data to which no adjustment command is provided
¶¶
Mod Main
