8.2 FACTORY MENU
8.2.1 INFORMATION
¶ Operation items
No. Display Item Content
RS-232C
Command
1 VERSION (1)
The software version for each flash memory is displayed.
QS1
2 MAIN NG The data on a shutdown generated in the Main side and its time are displayed. QNG, CNG
3 TEMPERATURE The current temperature and the rotation status of the fan are displayed. QMT
4 HOUR METER The HOUR METER/P-COUNT information are displayed. –
5 HDMI SIGNAL INFO 1
The data on the Status Register of the HDMI Receiver are displayed in hexadecimal
notation.
–
6 HDMI SIGNAL INFO 2
7 VDEC SIGNAL INFO Display the Signal Information on VDEC. –
Note: MULTI PRS stands for MULTI PROCESSOR and SEQ PRS stands for SEQUENCE PROCESSOR.
29 to 32 rows: Boot version of each device is displayed.
19 to 24 rows: The version of the execution program is displayed.
Screen: VERSION (1)
The software versions for each microcomputer is displayed.
NNIFOR
EVRSI (N1)O
/IF 1–
AMIN 0–
2A
2M
0–2M
0–3AM_
0–2Y
0A1
0A1
0A
A
P
1
01
UMLTI PRS
OMDULE
ESQPRS
AMTIO
V–D1 3 1010 –NTV WJ–M7
1
5
10
15
16
15 10 15 20 25 30 35 40
Microcomputer On-Screen Display
Display Example
(Execution program block)
Display Example
(Boot block)
I/F microcomputer I/F -12A –
Main microcomputer MAIN -02M 01A
Multiprocessor program MULTI PRS -02M 01A
Module microcomputer MODULE -03A_M 01A
Sequence processor program SEQ PRS -02Y 01A
8.2.1.1 VERSION (1)
