9.3.3 QIP
Data Arrangement
Data
Length
Output Example
ECO 3 Byte QIP
1 SERIAL 15 Byte - - - - - - - - - - - - - - -
2 HOUR METER 8 Byte 00000000
3 TOTAL HR MTR 8 Byte 00000000
4 PON COUNTER 8 Byte 00000000
5 TEMP1 acquisition (Temperature value) 5 Byte +23.5
6 TEMP0 acquisition (Not used) 5 Byte +00.0 (Fixation)
7 MAX-TEMP1 acquisition (Temperature value) 5 Byte +78.3
8 Reserved 4 Byte ∗∗∗∗
CS 2 Byte 94
Command
Format
Effective Operation
Modes
Function Remarks
[QIP] All operations
To acquire data on operations of the panel
Return data: 3 (ECO)+58(DATA)+2(CS)= 63 Byte
7 Acquisition of other data on the panel • • • [QIP]
The command QIP is for acquiring data other than those available with QS1 (data necessary before turning the power on)
and QS2 (data to inform of operational status change).
• Data for the Hour Meter and Backup Hour Meter are transmitted according to the same rules as for QS2.
• Data for TEMP1 and MAX_TEMP1 are output in 5 characters. The first character is assigned to + or -, and the fourth character is
assigned as the decimal point. The maximum output value is +99.9. If an AD value greater than +99.9 is acquired, +99.9 will be retained.
