Pioneer PDP-5000EX Service Manual

PDP-5000EX
156
1234
1234
C
D
F
A
B
E
9.3.6 QPM
Data Arrangement
Data
Length
Output Example
ECO 3Byte QPM
1 Pulse meter B 1 8Byte 00000000
2 Pulse meter B 2 8Byte 00000000
3 Pulse meter B 3 8Byte 00000000
4 Pulse meter B 4 8Byte 00000000
5 Pulse meter B 5 8Byte 00000000
CS 2Byte E7
• The high-order 3 bytes stored in memory as pulse-meter counts for the 5 blocks are multiplied by 256 to be converted
to decimal, then the high-order 8 digits (the low-order 2 digits rounded off) are transmitted (the unit for response value
is million pulses).
Command
Format
Effective Operation
Modes
Function Remarks
[QPM] All operations To acquire data on operations of the panel Return data: 3 (ECO)+40(DATA)+2(CS)= 45 Byte
7 Acquisition of parameters • • • [QPM]
The command QPM is for acquiring the accumulated number of pulses for each of 5 blocks from the EEPROM.

Pioneer PDP-5000EX Specifications

General

Depth	98 mm
Width	1282 mm
Height	750 mm
Weight	39800 g
Pixel pitch	- mm
Product color	Black
Audio (L/R) in	1
Noise reduction	Yes
RMS rated power	13 W
Display diagonal	50 \
Display brightness	1000 cd/m²
Display technology	Plasma
Power requirements	AC 110 - 240 V, 50/60 Hz
Contrast ratio (typical)	3000:1
Power consumption (standby)	0.4 W
Power consumption (typical)	420 W
