Pioneer PDP-5000EX Service Manual

PDP-5000EX
154
1234
1234
C
D
F
A
B
E
9.3.4 QAJ
Data Arrangement
Data
Length
Output Example
ECO 3 Byte QAJ
1 V-SUS adjustment value 3 Byte 128
2 V-OFT adjustment value 3 Byte 128
3 V-RST-P adjustment value 3 Byte 128
4 Reserved 3 Byte ∗∗∗
5 XSB adjustment value 3 Byte 128
6 YSB adjustment value 3 Byte 128
7 YTG adjustment value 3 Byte 128
11 RYW adjustment value 3 Byte 128
12 R-REVISE setting value 1 Byte 0
13 G-REVISE setting value 1 Byte 0
8 YTW adjustment value 3 Byte 128
9 RSW adjustment value 3 Byte 128
10 YTB adjustment value 3 Byte 128
14 B-REVISE setting value 1 Byte 0
CS 2 Byte B7
• For each REVISE setting value, the level set for RRL, RGL, or RBL is transmitted as one character.
Command
Format
Effective Operation
Modes
Function Remarks
[QAJ] All operations To acquire data on operations of the panel Return data: 3 (ECO)+41(DATA)+2(CS)= 46 Byte
7 Acquisition of panel adjustment data (common data) • • • [QAJ]
The command QAJ is for acquiring data on the panel's factory-preset items that are common to the main unit and that
share the same memory.

Pioneer PDP-5000EX Specifications

General

Depth	98 mm
Width	1282 mm
Height	750 mm
Weight	39800 g
Pixel pitch	- mm
Product color	Black
Audio (L/R) in	1
Noise reduction	Yes
RMS rated power	13 W
Display diagonal	50 \
Display brightness	1000 cd/m²
Display technology	Plasma
Power requirements	AC 110 - 240 V, 50/60 Hz
Contrast ratio (typical)	3000:1
Power consumption (standby)	0.4 W
Power consumption (typical)	420 W
