4.10 CONNECTOR PIN DESCRIPTION
D3 : CN3601 (AKM1348)
D4 : CN3602 (AKM1348)
D5 : CN3603 (AKM1348)
D9 : CN3607 (AKM1348)
D10 : CN3608 (AKM1348)
D11 : CN3609 (AKM1348)
AD1 : CN1502 (AKM1348)
FHD DIGITAL ASSY
50FHD ADDRESS A ASSY
Pin No. Name Voltage [V] Name Pin No. Function
1 GND_D 0 GND_D 40 GND
2 DIV0 0 or 3.3 DIV0 39 Output timing control signal output
3 DIV1 0 or 3.3 DIV1 38 Output timing control signal output
4 GND_D 0 GND_D 37 GND
5 +3_3V 3.3 +3_3V 36 +3.3V power sypply
6 +3_3V 3.3 +3_3V 35 +3.3V power sypply
7 GND_D 0 GND_D 34 GND
8 LVDSGND 0 LVDSGND 33 GND
9NC-NC 32 Non-connection termial
10 DP 1 1.4 DP 31 LVDS differential signal D+ output
11 DN 1 1.4 DN 30 LVDS differential signal D- output
12 NC - NC 29 Non-connection termial
13 LVDSGND 0 LVDSGND 28 GND
14 NC - NC 27 Non-connection termial
15 CLKP 1 1.4 CLKP 26 LVDS differential signal CLK+ output
16 CLKN 1 1.4 CLKN 25 LVDS differential signal CLK- output
17 NC - NC 24 Non-connection termial
18 LVDSGND 0 LVDSGND 23 GND
19 NC - NC 22 Non-connection termial
20 CP 1 1.4 CP 21 LVDS differential signal C+ output
21 CN 1 1.4 CN 20 LVDS differential signal C- output
22 NC - NC 19 Non-connection termial
23 LVDSGND 0 LVDSGND 18 GND
24 NC - NC 17 Non-connection termial
25 BP 1 1.4 BP 16 LVDS differential signal B+ output
26 BN 1 1.4 BN 15 LVDS differential signal B- output
27 NC - NC 14 Non-connection termial
28 LVDSGND 0 LVDSGND 13 GND
29 NC - NC 12 Non-connection termial
30 AP 1 1.4 AP 11 LVDS differential signal A+ output
31 AN 1 1.4 AN 10 LVDS differential signal A- output
32 NC - NC 9 Non-connection termial
33 LVDSGND 0 LVDSGND 8 GND
34 GND_D 0 GND_D 7 GND
35 NC - NC 6 Non-connection termial
36 NC - NC 5 Non-connection termial
37 GND_D 0 GND_D 4 GND
38 GND_D 0 GND_D 3 GND
39 ADRPD 0 ADRPD 2 Address PD signal input
40 NC - NC 1 Non-connection termial
