PDP-5000EX
24
1234
1234
C
D
F
A
B
E
3. PCB PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560 Ω
47k Ω
0.5 Ω
1 Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k Ω
RN1/4PC F562 x 10
1
5621
Mark No. Description Part No.
LIST OF ASSEMBLIES
NSP 1..50 FHD ADDRESS ASSY AWV2295
NSP 2..50FHD ADDRESS A ASSY AWW1127
NSP 2..50FHD ADDRESS B ASSY AWW1128
NSP 1..50FHD SCAN ASSY AWV2401
2..50FHD SCAN A ASSY AWW1229
2..50FHD SCAN B ASSY AWW1230
NSP 1..DIGITAL SENSOR ASSY AWV2290
2..FHD DIGITAL ASSY AWW1115
2..PANEL SENSOR ASSY AWW1116
NSP 1..FHD FUKUGO ASSY AWV2291
2..FHD POWER AMP ASSY AWW1117
2..FHD PRE AUDIO ASSY AWW1118
2..FHD SP LR1 ASSY AWW1119
2..FHD SP LR2 ASSY AWW1120
2..FHD LED ASSY AWW1121
2..FHD FAN CONNECT ASSY AWW1122
2..FHD IR ASSY AWW1123
2..FHD KEY ASSY AWW1124
2..FHD KEY CONTROL ASSY AWW1125
2..FHD RS232C+SR ASSY AWW1126
1..FHD MAIN ASSY AWV2292
1..50FHD X DRIVE ASSY AWV2293
1..50FHD Y DRIVE ASSY AWV2294
Mark No. Description Part No.
Unit Name: 50FHD SCAN A ASSY
SEMICONDUCTORS
IC 2701-2709 SN755870KPZT-P
D 2701 1SS355
D 2702-2707 1SS302
MISCELLANEOUS
CN2701 13P CONNECTER AKP1261
CN2702-2707 90PIN CONNECTOR AKM1358
RESISTORS
R 2705,2710,2713,2716 RAB4C221J
R 2719,2722,2725,2728 RAB4C221J
R 2731 RAB4C221J
R 2791 RS1/8SQ104J
R 2792 RS1/8SQ124J
Other Resistors RS1/16S###J
CAPACITORS
C 2701,2702,2711,2712 ACG1088
C 2703,2713,2723,2733 CKSRYB105K6R3
C 2704,2706,2707,2714 CCSRCH390J50
C 2708-2710,2718-2720 CCSRCH181J50
C 2716,2717,2724,2726 CCSRCH390J50
C 2721,2722,2731,2732 ACG1088
C 2727,2734,2736,2737 CCSRCH390J50
C 2728-2730,2738-2740 CCSRCH181J50
C 2741,2742,2751,2752 ACG1088
C 2743,2753,2763,2773 CKSRYB105K6R3
C 2744,2746,2747,2754 CCSRCH390J50
C 2748-2750,2758-2760 CCSRCH181J50
C 2756,2757,2764,2766 CCSRCH390J50
C 2761,2762,2771,2772 ACG1088
C 2767,2774,2776,2777 CCSRCH390J50
C 2768-2770,2778-2780 CCSRCH181J50
C 2781,2782 ACG1088
C 2783 CKSRYB105K6R3
C 2784,2786,2787 CCSRCH390J50
C 2788-2790 CCSRCH181J50
Unit Name: 50FHD SCAN B ASSY
SEMICONDUCTORS
IC 2801-2809 SN755870KPZT-P
D 2801 1SS355
D 2802-2807 1SS302
MISCELLANEOUS
CN2801 13P CONNECTER AKP1261
CN2802-2807 90PIN CONNECTOR AKM1358
RESISTORS
R 2805,2810,2813,2816 RAB4C221J
R 2819,2822,2825,2828 RAB4C221J
R 2831 RAB4C221J
R 2891 RS1/8SQ104J
R 2892 RS1/8SQ124J
Other Resistors RS1/16S###J
CAPACITORS
C 2801,2802,2811,2812 ACG1088
C 2803,2813,2823,2833 CKSRYB105K6R3
C 2805-2807,2815-2817 CCSRCH390J50
C 2808-2810,2818-2820 CCSRCH181J50
C 2821,2822,2831,2832 ACG1088
Mark No. Description Part No.
To Next Page
