PDP-5000EX
122
1234
1234
C
D
F
A
B
E
¶ Input signal-Mode Table
1st and 2nd charecters : Resolutin of the input signal ( numerics for the video signals, and alphabetics for the PC signals )
3rd and 4th charecters : Refresh rate of the input signal
5th charecter : Selection of the screen size
Input signal mode table for video signals (resolutions and V frequencies)
Input signal mode table for PC signals (resolutions and V frequencies)
Current selection of the screen size
Fv: Vertical Frequency, Fh: Horizontal Frequency
Fv: Vertical Frequency, Fh: Horizontal Frequency
¶: available, −: not available
1st and 2nd 3rd and 4th Signal Type Fv (Hz) Fh (kHz)
10 50 SDTV*625i 50.000 15.625
20 50 SDTV*625p 50.000 31.250
30 50 HDTV*1125i 50.000 28.125
40 50 HDTV*750p 50.000 37.500
10 60 SDTV*525i 60.000 15.734
20 60 SDTV*525p 60.000 31.469
30 60 HDTV*1125i 60.000 33.750
40 60 HDTV*750p 60.000 45.000
50 24 HDTV*1125p 24.000 27.000
50 50 HDTV*1125p 50.000 56.25
50 60 HDTV*1125p 60.000 67.5
5th Description on GUI VIDEO PC Remarks
0 DOT BY DOT
¶
¶
1 4:3
¶¶
2 FULL (FULL1)
¶¶
3 ZOOM
¶
−
4 CINEMA
¶
−
5 WIDE
¶
−
6 FULL 14:9
¶
−
7 CINEMA 14:9
¶
−
8 FULL2 For Japan only
¶ −
1st and 2nd 3rd and 4th Signal Type Fv (Hz) Fh (kHz)
C1 70 720 x 400 70.08 31.46
C2
60
640 x 480
60.00 31.50
72 72.80 37.90
75 75.00 37.50
C4
56
800 x 600
56.00 35.20
60 60.00 37.90
72 72.00 48.10
75 75.00 46.90
C6 60 1280 x 720 60.00 44.70
C7
60
1024 x 768
60.00 48.40
70 70.00 56.50
75 75.00 60.00
C8
56
1280 x 768
56.25 45.10
60 59.87 47.80
70 69.84 56.10
D1 75 1152 x 864 75.00 67.50
D4 60 1600 x 900 59.8 55.93
D5 60 1280 x 960 60.00 60.00
D6
60
1280 x 1024
60.02 63.981
75 75.025 79.976
D7
60
1400 x 1050
59.978 65.317
75 74.867 82.278
D8 60 11680 x 1050 59.954 65.29
D9 60 1920 x 1080 60 67.5
E0 60 1600 x 1200 60 75
E1 60 1920 x 1200 59.95 74.038
