Pioneer PDP-5000EX - Page 64

PDP-5000EX
64
1234
1234
C
D
F
A
B
E
X5: CN1204 (AKM1277) P6: (B6B-PH-K-S)
FHD X DRIVE ASSY
POWER SUPPLY UNIT
Pin No. Name Voltage [V] Name Pin No. Function
1 +60V 60 +60V 1 60V power supply
2 +60V 60 +60V 2 60V power supply
3NC - NC 3 Non-connection termial
4 GND_ADR 0 GND_ADR 4 GND
5 +12V 12 +12V 5 12V power supply
6 GND_D 0 GND_D 6 GND
X4: CN1202 (AKM1276) AD2: CN1501 (AKM1276)
FHD X DRIVE ASSY
FHD ADDRESS A/B ASSY
X7: CN1205 (AKM1276) AD2: CN1701 (AKM1276)
Pin No. Name Voltage [V] Name Pin No. Function
1 +60V 60 +60V 5 60V power supply
2 GND_ADR 0 GND_ADR 4 GND
3 8V 8 8V 3 8V power supply
4 5V 5 5V 2 5V power supply
5 GND_D 0 GND_D 1 GND
X3: CN1201 (AKM1281) AD2: CN1501 (AKM1276)
FHD X DRIVE ASSY
FHD ADDRESS A/B ASSY
X6: CN1203 (AKM1281) AD2: CN1701 (AKM1276)
Pin No. Name Voltage [V] Name Pin No. Function
1 GND_D 0 GND_D 1 GND
2 5V 5 5V 2 5V power supply
3 8V 8 8V 3 8V power supply
4 GND_ADR 0 GND_ADR 4 GND
5 +60V 60 +60V 5 60V power supply
6 +60V 60 +60V 1 60V power supply
7 GND_ADR 0 GND_ADR 2 GND
8 8V 8 8V 3 8V power supply
95V55V 4 5V power supply
10 GND_D 0 GND_D 5 GND
