Dolby Atmos, Dolby TrueHD, Dolby Digital, Dolby Digital Plus, DTS, DTS:X,
DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS 96/24, DTS-
ES, DTS Express, IMAX DTS, IMAX DTS:X, DSD, PCM
HDCP version
2.3
Maximum Video Resolution
4K 60 Hz (YCbCr 4:4:4)
Video Inputs
Component
IN1 (BD/DVD), IN2 (GAME)
Composite
IN1 (CBL/SAT), IN2 (STRM BOX)
Supported input resolutions
HDMI input
4K, 1080p/24, 1080p, 1080i, 720p, 480p/576p
Component input
480i/576i
Composite input
480i/576i
• The output from the HDMI OUT jack to the TV is the same resolution as the
input. When using a TV that supports 4K, 1080p HDMI video signals can also
be output as 4K.
Audio Inputs
Digital
OPTICAL (GAME, CD, TV)
COAXIAL (BD/DVD, CBL/SAT)
Analog
CBL/SAT, STRM BOX, BD/DVD, GAME, CD, TV, PHONO
Audio Outputs
Analog
PRE OUT (FRONT L/R, CENTER, SURR L/R, SURR BACK L/R, HEIGHT
1 L/R, HEIGHT 2 L/R, 2 SUBWOOFER)
ZONE B LINE OUT or ZONE 2 PRE/LINE OUT
ZONE 3 PRE/LINE OUT
Speaker Outputs
FRONT L/R, CENTER, HEIGHT 2 L/R or ZONE 2 L/R or SP-B,
SURROUND BACK L/R, SURROUND L/R or SP A, HEIGHT 1 L/R or Bi-
AMP L/R or ZONE 3 L/R (North American models support banana plugs.)
Phones
PHONES (Front, ø 6.3 mm, 1/4")
Others
Setup Mic : 1 (Front)
USB : 2 (Ver. 2.0, 5 V/0.5 A (Front/Rear))
Ethernet : 1
RS232 : 1
IR IN : 2
IR OUT : 1
12V TRIGGER OUT : 2 (A: 100 mA, B: 25 mA)
Specications and features are subject to change without notice.
