Combination example when Top Front
Speakers are used at the front
About the top front speakers
a
a: 30° to 55°
The top front speakers are installed on the ceiling at front of the listening
position, and the width between the left and right speakers is optimal to match
the one for the front speakers. When the top front speakers are used in front, the
combination of the height speakers at the rear can be selected from the following
4 examples shown at the right.
9,10 Top Front Speakers
(Example 1) Use top rear speakers at the rear
b
b: 125° to 150°
The top rear speakers are installed on the ceiling at rear of the listening position,
and the width between the left and right speakers is optimal to match the one for
the front speakers.
11,12 Top Rear Speakers
Speaker Layouts and Selectable Listening
Modes ( p136)
To Next Page
