15 HELP MESSAGES
100 Planmeca ProOne User’s Manual
H04-001 USB Communication The system cannot recognize the
connected USB device.
Only a USB memory stick can be
plugged into the USB port.
H04-003 Ethernet No network connection.
Check the connection and cabling.
H04-021 Imaging program Status The imaging program is not ready.
Select panoramic exposure in the
Romexis imaging program.
H04-022 USB Software update The software on the USB memory stick
is not suitable.
Check the software file.
H04-023 USB Memory stick full The USB memory stick is full and no
more images can be saved to it.
Use an empty USB memory stick or, to
create free memory space, delete
images from the USB memory stick after
you have sent the images to a PC.
H04-024 Imaging program Status The exposure program cannot be
changed (AF ON).
First close the imaging session in
Romexis. You can then change the
exposure program.
H05-020 USB Power supply The USB power supply current is too
high.
Only a USB memory stick can be
plugged into the USB port. Check that
the memory stick is not defective or
damaged.
H05-021 Frankfort positioning
light
The Frankfort laser power supply
current is too high.
To replace the Frankfort laser light,
contact your service technician.
H05-022 Midsagittal
positioning light
The midsagittal laser power supply
current is too high.
To replace the midsagittal laser light,
contact your service technician.
H05-023 Layer light The layer laser power supply current is
too high.
To replace the layer laser light, contact
your service technician.
H06-001 Emergency stop
button
Button activated The emergency stop button has been
activated.
All movements of the X-ray unit are
blocked, no radiation is generated.
Release the emergency stop button to
resume normal operation.
Code Explanation Comments
