Planmeca Sovereign - Installing Zeiss OPMI Pico Microscope

Planmeca Sovereign 111
INSTALLING THE PYLON AND ARM ACCESSORIES
Installation manual
9.7 Installing Zeiss OPMI pico microscope
The microscope arm is attached to the pylon openings marked with arrows (1).
Lift the microscope arm to its position. Make sure that the attachment screws are loosened so
that the they go into the openings on the pylon.
1
S199.eps
