Planmeca Sovereign 13
UNIT CONFIGURATION
Installation manual
The following picture presents the Planmeca Sovereign with side delivery arm and equipped
with the optional surgical and ortho tray table.
S228.eps
Cuspidor
Assistant
element
Patient
Side delivery arm
with hanging tube (HT)
instrument holders
Surgical and
Graphical
User
Interface
(GUI)
Monitor
chair
Bowl
OP delivery arm
ortho tray table
